MB MASTER concentrator allows communication with all data transmission modules that adopt the MBUS EN13757-3 standard.
It has been designed to manage networks consisting of M-Bus modules produced by B METERS water and heat meters. Available in 2 versions to support up to 60 or 250 network devices, it can handle up to 1200 m long network branches.
Equipped with an high contrast display it enables users to easily view present and historical consumption data up to 1 previous year (12 months values).
The MB MASTER is very easy to install and operate; the transmission modules configuration and data collection can be easily performed directly from the concentrator without having to reach the points where the various devices are individually installed.
Supplied with a user-friendly software and interface, allows to perform the consumption data reading operations (with the option to save up to 12 months of historical values), and export the data to a billing software.
Equipped with RS232USB interface is ready to be connected to any PC, or to Ethernet and GPRS network (expansion modules required).
| Operating temperature | from -20°C up to +55°C |
| Power supply | 55 – 250 VAC / 80 – 350 VDC |
| Protection rating | IP54 |
| Transmission protocol | MBUS Standard EN 13757-3 |
| Network cable (maximum length) | 1200 m |
| Dimensions (H x W x D) | 180 x 200 x 95 mm |
| Available data | Present consumption, up to 12 monthly historical consumption values |
| Number of connectable devices | 60 and 250 |
