UG63

Small in Size, Big on Connectivity

Mini LoRaWAN® Gateway

Mini Meets Mighty

UG63 is a 8-channel lightweight indoor LoRaWAN® gateway. Adopting, SX1302 chip, UG63 can set up packet forwarding connection between end nodes and mainstream network servers (such as TTN andChirpstack).

With its compact size and high performance, it is highly suitable for independent deployment of LoRaWAN® networks in small-scale scenarios or single spaces. It can also serve as a supplementary gateway, along with UG65/UG67 or other main gateways, to enhance LoRaWAN® signal coverage in large-scale scenarios by filling in signal blind spots. It is an ideal supplement for wide indoor areas such as office, parking lots andcampuses.

Features

Equip with SX1302 chip, handing a higher amount of traffic with lower consumption
8 half-duplex channels for more than 2000 end-nodes connections
Small in size for easy carrying & deployment
Desktop, wall or ceiling mounting support
Multi backhaul backups with Ethernet and Cellular (4G)
Cover the blind spot of LoRaWAN® network by transmitting data to Milesight UG56/UG65/UG
67 controller gateway
High cost performance, suitable for small applications
Milesight DeviceHub2.0 & IoT Developer Platform provide easy and centralised management of remote devices
Compatible with mainstream network servers like The Things Industries, ChirpStack, AWS IoT Core for LoRaWAN®

Small in Size,
Big on Connectivity

8 Channels
Up to 2000 End-Nodes
Up to 2 km Communication Range in Urban Areas
Global Frequency Plans
(RU864/IN865/EU868/US915/AU915/KR920/AS923-1&2&3&4)

LoRaWAN® Based

Penetrating Signals: data transmission range up to 2 km in urban areas
High Compatibility: compliant with standard LoRaWAN® sensor and network servers

Cost-Effective for
Small-Scale Deployments

UG63 is a cost-effective device designed to provide network coverage for numerous yet dispersed small-scale applications where the number of end nodes is limited, but each area requires its own gateway.

Eliminating Blind Spots

UG63, in collaboration with remote LoRaWAN® network server, can provide complementary network coverage to achieve comprehensive LoRaWAN® network coverage, leaving no blind spots in corner regions or weak signal regions
