SG50

Ultra Low Power Solar LoRaWAN® Gateway

SG50 is an energy-efficient solar LoRaWAN® gateway designed for outdoor environments with limited power availability and ample solar energy resources.

With built-in batteries and an accessorial solar panel, the SG50 can work independently in various scenarios, especially in places with hard access to power resources.

Besides the high adaptability, SG50 is highly compatible with mainstream network servers and supports remote management via remote network servers, which provides both convenience and secure management.

Benefiting from its robust structural design and high IP67 protection rate, the SG50 can work smoothly in harsh environments. It is specifically tailored for applications such as oil and gas, mining, forestry, and remote industries where power consumption must be carefully managed.

Features

IP67 enclosure and robust structural design promote its strength and working lifespan
Equip with SX1302 chip, handling a higher amount of traffic with lower consumption
Support 8 channels for more than 2000 end-nodes connections
Equip with GPS for simple remote management and deployment
Fast deployment with the all-in-one design and standard accessories
Built-in rechargeable batteries & accessorial solar panel for wireless usage
Support cellular for backhaul network enabling independent networking
Compatible with mainstream network servers like The Things Stack, ChirpStack, etc.
Embedded network server and MQTT API for easily integration
Equip with a high-efficiency power management design, prolonging its battery life up to 4 days
Compatible with remote management system for simple deployment even in remote regions
