Wireless M-BUS module for GSD8-I water meters
IWM-TX5 is designed to enable wireless remote reading in different types of applications in the residential, commercial and industrial sectors. The radio module, thanks to the presence of the inductive target in the meter dial, allows the reading of the volume consumption without on-site intervention, in walk-by mode or AMR (automatic meter reading), in respect of the WMBUS standard.
Features:
Radio interface | W-Mbus EN13757-4 @868 MHz ≤ 25 mW, mode T1 |
Coverage | 300 meters* |
Compatible water meters | GSD8-I |
Pulse output minimum value (K) | 1 litre |
Configuration | NFC |
Energy supply | Non-replaceable lithium battery 3.0V, maximum lifetime 10 years** |
Protection class | IP65, IP68*** (on request) |
Weight | 57g |
Size (l x p x h) | 70 x 90 x 30 mm |
Working temperature | from +1° to +55°C |
Alarms | Volume (consumption), total of reverse flow, 12 monthly historical values, alarms |
Maximum reading error | 0.5% |
Module programming requirements (optional) | Bmetering software on Microsoft Windows. NFC Android device and BMetering NFC Config app freely downloadable GOOGLE PLAY. |
* In optimal signal transmission conditions
** The battery life strongly depends on the working time window, set during the configuration process, and on the environmental conditions
*** IP68: maximum 24 hours of continuous submersion at 1 m depth
