CPT Turbine Gas Meter

CPT Quantometers Inline Turbine Gas Meter suitable for natural gas & LPG

CPT Turbine Gas Meter

CPT Quantometers Inline Turbine Gas Meter suitable for natural gas & LPG

CPT Quantometers have been designed in order to provide our customers with reliable and inexpensive measuring instruments for secondary flows.

CPT-Quantometer-CO-flanged

At a glance

Inline turbine gas meters with wafer connections to suit PN16 flanges
Fitted with low-frequency pulse output as standard – multiple LF & HF options available
Aluminium body, suitable for natural gas and LPG, -20°C to +60°C
Biogas option available, filter recommended for this media.
For horizontal or vertical pipelines with 5 x DN straight lengths of pipe up stream
Nominal rangeability 1:20, meters read in cubic meters, index can be head rotated through 350°

Installation and operation Instructions

Technical Data

Model	DN mm	Minimum Flow Rate m3/h	Maximum Flow Rate m3/h	Connections
CPT/25GXX	25	2.5	40	BSP Screwed
CPT/30GXX	30	2.5	40	BSP Screwed
CPT/40GXX	40	6	100	BSP Screwed
CPT/50GXX	50	6	100	BSP Screwed
CPT/50GXX	50	6	100	Wafer Pattern PN16
CPT/65GXX	65	8	160	Wafer Pattern PN16
CPT/80GXX	80	8	400	Wafer Pattern PN16
CPT/100GXX	100	13	650	Wafer Pattern PN16
CPT/150GXX	150	30	1600	Wafer Pattern PN16
CPT/200GXX	200	50	2500	Wafer Pattern PN16
