AM104/AM107

Improving Energy Efficiency and Indoor Comfort

Indoor Air Quality (IAQ) Monitoring

AM104/AM107 is a comprehensive IAQ sensor for detecting CO₂ concentration, temperature, humidity, light, TVOC, barometric pressure, and motion.

AM104/AM107 is a compact indoor ambience monitoring sensor for measurement of temperature, humidity, light, CO₂ concentration, TVOC, barometric pressure and motion. These data will be shown on the E-ink screen in real-time, which allow to quantify the indoor environment and comfort. AM104/AM107 is widely used for offices, stores, classrooms and hospitals.

Apart from screen display, sensor data is also transmitted using LoRaWAN® technology. With this low power consumption technology, AM104/AM107 can work for one year with 2 replaceable AA batteries. Combining with Milesight LoRaWAN® gateway and Milesight IoT Cloud solution, users can manage all sensor data remotely and visually.

Features

Integrated with multiple sensors like humidity, temperature, CO₂, light, barometric pressure, etc.
Visual display via E-ink screen
Standard AA batteries
One year work without replacing batteries
Equipped with NFC and type-C port for easy configuration
Compliant with standard LoRaWAN® gateways and network servers
Quick and easy management with
Milesight IoT Cloud solution

LoRaWAN® Based

Penetrating Signals: data transmission range up to 2 km in urban areas and 15 km in rural areas
High Compatibility: compliant with standard LoRaWAN® gateways and network servers
